Production Dates: July 2004 - June 2014
Serial #: 01001 - 10079
MAIN ASSEMBLY
Item Description (Part Number)
QTY: 1 Bottom Casting (2010-410) +$492.20
QTY: 2 Top Casting (2010-490) +$492.20
QTY: 3 Corner Column Casting [4 per unit, each sold separately] (2010-420) +$184.04
QTY: 4 Door Frame [recommend a Front Door Support Kit as these Parts need to be Machine together] ~Old Part # 2010-440~ (90-85410) +$409.71
QTY: 4A Tribute Front Door Support ReplaCement Kit [Matte Black] [includes: Inner Door Frame, Outer Door, Glass, Gaskets, Door Latch and Hardware] [recommend replacing Handle and getting extra Striker] (90-854010) +$509.25
QTY: 4B Tribute Front Door Support ReplaCement Kit [Brown Enamel] [includes: Inner Door Frame, Outer Door, Glass, Gaskets, Door Latch and Hardware] [recommend replacing Handle and getting extra Striker] (90-854020) +$640.00
QTY: 4C Tribute Front Door Support ReplaCement Kit [Blue Black Enamel] [includes: Inner Door Frame, Outer Door, Glass, Gaskets, Door Latch and Hardware] [recommend replacing Handle and getting extra Striker] (90-854059) +$640.00
QTY: 4D Tribute Front Door Support ReplaCement Kit [Seafoam Enamel] [includes: Inner Door Frame, Outer Door, Glass, Gaskets, Door Latch and Hardware] [recommend replacing Handle and getting extra Striker] (90-854061) +$640.00
QTY: 4E Tribute Front Door Support ReplaCement Kit [Moss Enamel] [includes: Inner Door Frame, Outer Door, Glass, Gaskets, Door Latch and Hardware] [recommend replacing Handle and getting extra Striker] (90-85410-81) +$1790.64
QTY: 4F Tribute Front Door Support ReplaCement Kit [Basil Enamel] [includes: Inner Door Frame, Outer Door, Glass, Gaskets, Door Latch and Hardware] [recommend replacing Handle and getting extra Striker] (90-85410-83) +$1790.64
QTY: 4G Front Door Striker (5021-056) +$66.63
QTY: 4I Reversible Lock Nut [2 for Bottom Holes of the Door Support Kits] (4200-0300) +$12.65
QTY: 5 Primary Air Plenum (2010-430) +$237.64
QTY: 6 Door - Matte Black (2010-450) +$299.59
QTY: 6A Door - Brown Enamel (2020-450) +$458.09
QTY: 6B Door - Black Enamel (2050-450) +$419.12
QTY: 6C Door - Blue Black Enamel (2059-450) *No Longer Available* +$*0.00*
QTY: 6D Door - Seafoam Enamel (2061-450) +$420.34
QTY: 6E Door - Moss Enamel (2081-450) *No Longer Available* +$*0.00*
QTY: 6F Door - Basil Black Enamel (2083-450) *No Longer Available* +$*0.00*
QTY: 7 Glass Kit [includes: Gasket, Clips, Screws] (90-58405) +$229.77
QTY: 9 Front Door Latch Kit [includes: Set Screw, Door Latch Spacers, Spring, Chrome Door Crank, Door Latch] (90-73212) +$135.12
QTY: 11 Wood Handle with Bolt and Washer (90-71100) +$18.75
QTY: 12 Secondary Air Manifold, Top (2010-470) +$202.31
QTY: 13 Secondary Air Manifold, Bottom (2010-480) +$349.69
QTY: 14 Secondary Air Riser Pipe (5040-050) +$99.69
QTY: 15 Secondary Air Tube # 2 [Front] (5040-052) +$91.70
QTY: 16 Secondary Air Tube # 1 [Rear] (5040-051) +$68.03
QTY: 17 Baffle Support (5040-070) +$149.13
QTY: 18 Ceramic Baffle with Retrofit Bracket and Wire ~Old Part # 3120-040~ (90-76400) +$98.70
QTY: 19 Primary Air Control Slide (5021-025) +$27.35
QTY: 21 Front Lower Stone [2 per unit, each sold separately] (1041-430) +$57.90
QTY: 22 Front Upper Stone [2 per unit, each sold separately] (1041-450) +$46.60
QTY: 23 Matte Foot [4 per unit, each sold separately] (2010-210) +$113.66
QTY: 24 Side Stone [4 per unit, each sold separately] (1041-420) +$Call to Order
QTY: 24A Side Stone Trim [each sold separately] (2010-460) +$Call to Order
QTY: 25 Top Side Stone [2 per unit, each sold separately] (1041-460) +$206.94
QTY: 26 Top Center Stone (1041-470) +$113.66
QTY: 27 Rear Stone [4 per unit, each sold separately] (1041-410) +$177.95
QTY: 28 Matte Rear Stone Trim (2010-275) +$113.66
QTY: 29 Front Side Stone [4 per unit, each sold separately] (1041-440) +$57.90
QTY: 30 Flue Collar (2010-285) +$206.94
QTY: 31 Left Bottom Refractory Stone (1-0000-400) +$72.24
QTY: 32 Right Bottom Refractory Stone (1-0000-100) +$66.63
QTY: 33 Primary Air Slider Bracket (5021-020) +$47.87
QTY: 34 Primary Air Control Handle (5040-030) +$93.33
QTY: 50 Threaded Rod 1/4-2x19 (5210-3070) +$14.34
QTY: 51 Threaded Rod 1/4-20x20-1/4 (5210-3060) +$23.35
QTY: 52 Tie-Rod Sleeve (5040-080) +$47.87
QTY: 53 Side Spline [2 per unit, each sold separately] (5000-005) +$Call to Order
QTY: 54 Rear Slotted Spline (5000-023) +$38.98
QTY: 55 Rivet [Door Pin] [2 per unit, each sold separately] (4400-0300) +$10.95
QTY: 56 Washer [2 per unit, each sold separately] (4600-1210) +$10.95
ITEMS NOT SHOWN - MAIN ASSEMBLY
Item Description (Part Number)
QTY: 60 Gasket Kit [includes: Front, Glass Gaskets and Gasket Glue] (90-58400) +$87.49
QTY: 61 Gasket: Rope [sold per foot] (3110-056) +$10.95
QTY: 62 Gasket: Rope [sold per foot] (3110-059) +$11.40
QTY: 63 Gasket: Glass Clip [6 per unit, each sold separately] ~Old Part # s 3120-059, 3120-021~ (3120-351) +$11.95
QTY: 64 Gasket Glue (99-090N) +$45.77
QTY: 65 One Piece Latch [Screws into the Inner Frame] (5021-022) +$61.03
QTY: 66 Screw for Latch [2 per unit, each sold separately] (4500-3430) +$10.95
QTY: 67 Shutter Bushing (5550-155) +$45.77
ACCESSORIES
Item Description (Part Number)
QTY: 68 Spark Screen (90-69400) +$132.14
QTY: 69 Rear Heatshield (90-68400) *No Longer Available* +$*0.00*
QTY: 70 Convection Blower (90-57210) +$439.00
QTY: 71 Outside Air Adapter (90-53400) +$82.95
QTY: 72 Gloves (90-99031) +$66.00
QTY: 73 Soapstone Steamer with Blue Black Enamel Lid (90-99112) +$199.00
QTY: 74 Soapstone Stovetop Thermometer (90-99120) +$30.00
QTY: 75 Owners Manual [hard copy] [6400-40447] (OMHC-H) +$9.99
QTY: 76 Owners Manual [electronic copy] [6400-40447] (OMEL-H) +$0.00
QTY: 77 Furnace Cement (6300-34080) +$37.52
|
